Liquid Lock in Piping: Hidden Risks and How to Prevent Them

スポンサーリンク
construction-design
記事内に広告が含まれています。This article contains advertisements.

Liquid lock (also called hydro-lock) is a silent yet dangerous phenomenon in chemical plants. It often goes unnoticed until serious damage occurs. While operators in manual systems may recognize and prevent it, the risk increases as automation grows. Even small temperature changes can cause enormous pressure, damaging pipes, valves, and equipment. This article explains the basics of liquid lock, why it happens, and practical ways to prevent it.


What is Liquid Lock?

Liquid lock occurs when liquid is trapped inside a closed section of piping and its temperature rises. As the liquid expands, pressure builds because it has no escape path. This pressure can quickly exceed the pipe’s design limit, leading to leaks, ruptures, or equipment failure—even with just a few degrees of temperature change.

Thermal Expansion and Compression

  • Expansion: Liquids expand when heated. For water, a 5 °C increase can generate pressures exceeding 2 MPa. Many chemical plant pipes are not designed to withstand this.
  • Compression: When liquid expansion is restricted, the surrounding pipe or valve compresses, creating dangerous stress.

Where Does It Happen?

  1. Automatic Valves
    • If two automated valves close around a section of pipe, liquid lock can occur.
    • Unless the system sequence includes a pressure relief step, trapped liquid will damage the line.
    • Solutions: add a relief valve, or briefly reopen one valve after shutdown.
  2. Ball Valves
    • Ball valves can trap liquid inside their cavity when closed.
    • As temperature rises, internal pressure may force leaks at the weakest seal.
    • Many manufacturers design relief ports to release trapped pressure safely.
  3. Freezing (a special case)
    • When water freezes, it expands.
    • Ice formation inside pipes causes the same destructive effect as liquid lock.
    • Cracks often appear unnoticed until thawing reveals leaks.

Why It’s Dangerous

  • Even a normal day–night temperature difference of 5 °C can trigger liquid lock.
  • Leaks may release hazardous chemicals to the atmosphere.
  • Equipment damage can lead to costly shutdowns and safety risks.

Conclusion

Liquid lock is often overlooked because the principle is simple—but its consequences are severe. Whether designing, operating, or maintaining chemical plant systems, always consider liquid lock risks. Automatic valves, ball valves, and freezing are common sources. Adding relief valves, designing safe escape paths, and understanding the physics behind liquid expansion are key steps to preventing accidents.
