L-Type vs. J-Type Anchor Bolts: What’s the Difference?

LJ
記事内に広告が含まれています。This article contains advertisements.

Anchor bolts are critical for securing equipment and structures to concrete foundations. But not all anchor bolts are the same. In particular, the L-type and J-type bolts often confuse beginners. They may look similar—but they behave very differently.

This beginner-friendly guide explains the key differences, how each type is used, and what you need to consider when choosing between them.


🔩 What Are L-Type and J-Type Anchor Bolts?

Both are bent anchor bolts embedded in concrete to secure equipment or steel frames.

  • L-Type bolts are shaped like the letter “L”.
  • J-Type bolts are shaped like the letter “J”.

At first glance, the difference seems small—but their strength and reliability can vary.


⚠️ Which One Is Stronger?

The L-Type bolt is generally stronger and more stable than the J-Type. The sharp bend and longer embedded length of the L shape create more resistance inside the concrete, especially during upward or pulling forces.

The J-Type is easier to bend and may fail more easily under heavy loads or seismic conditions.


🛠 Why Do People Still Use J-Type Bolts?

Some manufacturers still produce J-Type bolts because:

  • They are easier and cheaper to make.
  • They are sometimes enough for light loads or temporary installations.
  • In some markets, they are still the default or traditional choice.

But in modern plant construction, L-Type bolts are preferred for safety and long-term durability.


🧾 What’s LA and JA?

Sometimes you’ll see bolts labeled as LA or JA instead of just L or J.
These terms come from manufacturer naming and are often used in catalogs.

  • LA = L-Type Anchor
  • JA = J-Type Anchor

They’re the same shapes as L and J, just using shorthand codes.


✅ Conclusion

If you’re designing or checking anchor bolts for equipment foundations, always check the type—especially in earthquake-prone areas or for heavy loads. L-Type bolts offer better resistance and are generally a safer choice. J-Type bolts may look similar, but they’re not interchangeable.

When in doubt, go with L-Type.
